∎Technical Specification
| Sample flow | Recommended: 0 – 5 l/min UV254 Spectroscopy with Double beam full spectrum Analysis |
| Sample pressure | 0 – 4 Bar (0 – 1 Bar with sampling peristaltic pump) |
| Sample temperature | 0 – 80 °C |
| PH RANGE | 0-14ph |
| TSS RANGE | 0 – 1000 mg/l |
| BOD RANGE | 0 – 1000 mg/l |
| COD RANGE | 0 – 1000 mg/l |
| TDS RANGE | 0 – 1000 mg/l |
| Temperature Range | -10 to 100 Deg C |
| Wet parts materials | Quartz, Polypropylene, Polyethylene, FPM (viton), PMMA |
| Measurement interval | 1 min to 720 min (If measuring time compatible) |
| Memory | 5000 lines of measurements (up to 16 channels) with date and time |
| Consumption | Cleaning solution (5% sulphuric acid): 220 ml/day |
| Maintenance interval | Recommended: 6 months to 1 year (except for refilling) |
| Power supply | 90 – 264 VAC 50/60 Hz 40 VA – 12v DC 3A maxi 4-20 Ma outputs |
| Screen | Colour TFT LCD 320x240 pixels with LED backlight |
| Ingress Protection | IP 65” |
| Communication | RS232, Modbus or HTTP/Web interface, compatible with Windows7, with Internet Explorer version 9, Nexus 7 tablet under Android with Opera version 12.10, Apple I-phone 4S with Safari |
