for Air/Gas/Stream/Liquid Application

∎Technical Specification

Enclosure	S.S.316
Flange	S.S.316
Connection	Flange End
Accuracy	+/- 1 FSD
Repeatability	0.02%
Fluid &Ambient Temperature	(-40 to 350) Deg. C
Protection	IP – 67 / EX
Max .Working Pressure	60 Bar
Application	Conductive (Gas & Water, Steam Mixed water etc.) . Suitable For All Process Industries

Mass & Volumetric flow monitoring of most gases, liquids and steam
Measures five process variables with one process connection:
- Mass flow rate
- Volumetric flow rate
- Temperature
- Pressure
- Fluid density
Rugged, long-lasting design for the toughest applications
Sensors located behind bluff body are well protected from pressure shocks and water hammer

Easy to Install, lots of field installation options
Loop-powered design simplifies wiring and signal processing
Fully field configurable field-configuration
Energy (BTU) Monitoring for real-time monitoring of energy consumption; compute and output energy use
Rangeable down to Reynold's number of 5000
Field validation/configuration to assure operating performance
Flow totalizer and alarms
Reduced installation cost and improved performance
Reducer version eliminates the need for field-installed piping reductions
An insertion probe version up to 72 inches (2 m) in length - 241S
